GTA 09-06-038 Browning Machinegun, .50 Caliber
	MEDIA: 17 Color Charts SYNOPSIS: Instructional size 29"x42" 17 Black and White with some color charts. Charts 1-9 are printed on the front side; charts 10-17 are printed on the reverse side. These charts are bound together by cloth back tape with two rivets for hanging. These charts illustrate the assembly, disassembly, and operations of the weapon. Basic characteristics: Basic parts identification; Back plate assembly; Bolt group; Barrel buffer body group; Barrel extract group; Cover group; Retracting slide assembly; Receiver group; Feed change over. Major group thoroughly explains each and provides checks. These charts provide some operation. The image is a representation and not a true image.
Available at your local Training Support Center
Army customers should order through their installation Training Audiovisual Support Center (TASC). Trainers from other services must contact ATSC directly to arrange support. Questions and comments may be directed to: atsc.teamgta1@conus.army.mil.
